Rotating scalder RBK 3 and RBK 4

Category:

Description



The rotating scalder RBK 3 and RBK 4 with oil heating chamber has two scalding sections, because of continuous rotations this, results in a very effective scalding of the birds. This scalding system is ideally suitable for waterpoultry.

The scalder has an heat output of 4x 6 kW / 400 V.

The temperature is controlled by a digital controller. The heating elements can be switched on independently.



Substantial advantages :

  • The oil heating chamber is filled with heat conducting oil, this protects the

heating elements against soiling. Additionally, it serves as a heat

accumulator.

  • Because of the insulation the heating costs will be lowered.
  • Large drain
  • Very easy cleaning
  • Well-regulated slaughtering process



Water volume = RBK 3 = 250 L

RBK 4 = 320 L

24,55 kW; 400 V, 50Hz
